Eterna 12824 (ETA 2824)
Mechanical
c. 1940
Self-winding (rotor)
Date
Hacking
Notes
1975 still with the typical Eterna rotor
Dimensions
| Width | 25.6 lignes (57.75 mm) |
|---|---|
| Height | 4.6 mm |
| Stem height | 1.2 mm |
| Hands (H × M × S) | 1.5 × 0.9 × 0.25 mm |
Technical data
| Beat rate | 28,800 vph (4 Hz) |
|---|---|
| Lift angle | — |
| Power reserve | 40 h |
| Jewels | — |
| Shock protection | KIF |
| Mobile stud carrier | No |
Complications
| Self winding | Rotor |
|---|---|
| Date | Yes (quick set) |
| Day | No |
| Hacking | Yes |
| Chronograph | No |
Mainspring
| GR code | — |
|---|---|
| Height | 11 mm |
| Thickness | 0.12 mm |
| Length | — |
| Barrel diameter | 1.2 mm |
Overview
| Type | Mechanical |
|---|---|
| Manufacturer | Eterna |
| Year | c. 1940 |
| Family | — |
| Clone of | — |
Documents
None
Updated about 9 hours ago · 6 revisions
